WaterMark UF 12 / UF 30 softener

WaterMark UF 12 / UF 30 softener

compact softener

Low consumption water softening equipment with an innovative cabinet with an elegant design with a sliding salt lid and multicolor interactive display.

The technology of the WaterMark UF equipment saves up to 65% of water compared to other similar equipment.

Equipment made up of a GRP bottle with upper and lower ABS distributors and a polyethylene cabinet. Equipped with a new WS470 valve for low salt and water consumption with an advanced electronic programmer.

Vacation mode: during absences the equipment performs small washes without consuming salt.

Safety buoy, depending on the model, included.

Isolation by-pass included in the equipment.

Residual hardness mixer integrated in the head.

Connection by locking clips, reliable and fast.

Your Watermark water softener equipment provides you with the following benefits and advantages:

• Energy saving.
• Greater sense of well-being.
• Smooth and soft skin.
• Increases the useful life of household appliances and boilers.
• Economic savings: Reduce the consumption of soaps, softeners and chemical products.
• Low maintenance cost.
• Fully automatic operation.

Characteristics:

Min pressure: 2.5 kg/cm2

Max pressure: 6 kg/cm2

Min temperature: 4ºC

Max temperature: 40ºC

Power supply: 220 V – 12 Vac / 50 Hz

WaterMark UF 12

Characteristics

• Dimensions (height x width x depth): 750mm x 360mm x 550mm
• WEIGHT: 6kg
• Resin volume (l): 12.5
• Flow (m³/h): 1
• Maximum flow in (m³/h): 1.2
• Minimum feed flow in (m³/h): 0.4
• Tank capacity: 35 kg
• Connection diameter: ¾” M thread
• Min/max pressure working load: 2.5 kg/cm² – 8.6 kg/cm²
• Working voltage: 220V-12Vac/50Hz.
• Working temperature: from 4ºC to 35ºC
• Water consumption per regeneration: 105 l
• Mix Bypass: Yes

Table of capacities and salt consumption per regeneration:

• Minimum: 51.5 ºHFxm³ – 1 kg
• Medium: 57 ºHFxm³ – 1.4 kg
• Maximum: 66 ºHFxm³ – 1.9 kg

WaterMark UF 30

Characteristics

• Dimensions (height x width x depth): 1170 mm x 360 mm x 550 mm
• WEIGHT: 15kg
• Resin volume (l): 30
• Flow (m³/h): 2.4
• Maximum flow in (m³/h): 2.7
• Minimum feed flow in (m³/h): 0.4
• Tank capacity: 75 kg
• Connection diameter: 1” M thread
• Min/max pressure working load: 2.5 kg/cm² – 8.6 kg/cm²
• Working voltage: 220V-12Vac/50Hz
• Working temperature: from 4ºC to 35ºC
• Water consumption per regeneration: 160 l
• Mix Bypass: Yes

Table of capacities and salt consumption per regeneration:

• Minimum: 150 ºHFxm³ – 2.4 kg
• Medium: 180 ºHFxm³ – 3.6 kg
• Maximum: 230 ºHFxm³ – 7.5 kg
